6 - 4 TimeCutter™ Z Service Manual
CHASSIS
6
Remove the control arm.
Remove the electrical connector from the motion
control switch.
N
E
W
P
H
O
T
O
Remove the pin from the return to neutral yoke.
0702-0603
0702-0604
0702-0605
Remove and Replace Control Linkage
