A1-14 TimeCutter ZX Service Manual
1b
Specifi cations cont.
ZX 480 ZX 525
Engine: Briggs & Stratton Intek OHV, 441577 Kawasaki FH58V OHV
High Idle 3400 + 100 RPM 3400 + 100 RPM
Low Idle N/A 1400 RPM
Horse Power N/A N/A
Cubic Centimeter’s (cc’s) 725 Dispacement 585 Dispacement
Fuel Unleaded Gasoline 87 octane min. Unleaded Gasoline 87 octane min.
Oil Capacity 2 qts. (1.9 L) 1.9 qts. (1.8 L)
Charge coil 12v - 16 amp 12v - 13 amp
Construction:
Front Frame Welded 1x2x.120” structural steel tube Welded 1x2x.120” structural steel tube
Rear Frame Welded 7 & 10 ga. High strength steel Welded 7 & 10 ga. High strength steel
Frame Assembly Front & rear frames bolted together. Front & rear frames bolted together.
Deck Right side discharge, 48” cut, three
blade mid-mounted rotary. Drawn 12
gauge steel deck with gauge reinforced
plate and welded mounting brackets and
gauge.
Right side discharge, 44” cut, three blade
mid-mounted rotary. Drawn 12 gauge
steel with welded mounting brackets and
gauge wheel brackets. Frame supported.
Fuel System: Single fuel tank fender type mounted on
the left side.
Single fuel tank fender type mounted on
the left side.
Capacity 5 Gallons (18.9 L)
Fuel tank shut off
In-line fuel fi lter
5 Gallons (18.9 L)
Fuel tank shut off
In-line fuel fi lter
Traction System:
Transaxles Twin Hydro-Gear IZT Hydrostatic Trans-
axles with charge pumps & shock valves.
Twin Hydro-Gear IZT Hydrostatic Trans-
axles with charge pumps & shock valves.
Transaxle Drive Belt Drive with self-tensioning system Belt Drive with self-tensioning system
Ground speed forward Infi nite, 0 to 7.0-MPH (11.3-km/hr) Infi nite, 0 to 7.0-MPH (11.3-km/hr)
Ground speed reverse 0 to 3.4-MPH (5.5-km/hr) 0 to 3.4-MPH (5.5-km/hr)
Transport rods Allows unit to be moved without engine
running.
Allows unit to be moved without engine
running.
Attachment Drive:
Clutch Electric Electric
Type Vertical Drive with Single Deep B-Groove
Pulley
Vertical Drive with Single Deep B-Groove
Pulley
SPECIFICATIONS
