3 - 6 TimeCutter™ Z Service Manual
GREASING AND LUBRICATION
3
as well as the castor wheel bearings.
The zerk fitting for the traction belt idler bushing
is located under the seat.
Also under the seat are the fittings for the motion
control lever pivot bushings - one for each lever.
0702-0309
0702-0310
0702-0311
