5 - 20 TimeCutter™ Z Service Manual
TRANSAXLE
5
9. After you have adjusted the rods, move the
directional control handle in reverse position,
then let go of the handles. The handles
should move to the neutral position and the
drive wheels should remain stationary, or
have a very slight amount of creep in
reverse. The wheels should not creep in the
forward direction when the control handles
are in the neutral lock out position.
10. Run the engine at full throttle. Check neutral
again by moving the directional control
handles in reverse, then let go of the
handles. The handles should move to the
neutral position and the drive wheels should
not move. A slight creep could be observed
when the machine is elevated. However,
when lowering the unit to the ground, the
weight of the unit should stop the creep.
11. When the adjustment is complete, hold the
control rod stationary with pliers and tighten
the jam nuts. Always test again to make
sure the unit is still neutralized.
0702-0529
0702-0530
0702-0531
