CHASSIS
TimeCutter™ Z Service Manual 6 - 7
6
Use a small punch to drive the roll pin out of the
upper bellcrank lever, then remove the lever and
thrust washer.
Pull the lower lever and shaft from the bushing.
0702-0612
0702-0613
