Toro TimeCutter Z5000 User Manual

DrivingForwardorBackward
Thethrottlecontrolregulatestheenginespeedas
measuredinrpm(revolutionsperminute).Place
thethrottlecontrolintheFastpositionforbest
performance.Alwaysoperateinthefullthrottle
position.
Themachinecanspinveryrapidly.The
operatormaylosecontrolofthemachine
andcausepersonalinjuryordamagetothe
machine.
•Usecautionwhenmakingturns.
•Slowthemachinedownbeforemaking
sharpturns.
Figure15
1.Park(brake)position
3.Forward
2.Centerunlockposition
4.Backward
Forward
1.Movetheleverstothecenter,unlockedposition.
2.Togoforward,slowlypushthemotioncontrol
leversforward(Figure15).
G008952
Figure16
Togostraight,applyequalpressuretobothmotion
controllevers(Figure15).
Toturn,releasepressureonthemotioncontrollever
towardthedirectionyouwanttoturn(Figure15).
Thefartheryoumovethemotioncontrolleversin
eitherdirection,thefasterthemachinewillmovein
thatdirection.
Tostop,pullthemotioncontrolleverstoneutral.
Backward
1.Movetheleverstothecenter,unlockedposition.
2.Togobackward,slowlypullthemotioncontrol
leversrearward(Figure17).
G008953
Figure17
Togostraight,applyequalpressuretobothmotion
controllevers(Figure17).
19

Toro TimeCutter Z5000 Specifications

General

Cutting Width	50 inches
Deck Material	10-gauge steel
Warranty	3-year limited
Speed	Up to 7 mph
Turning Radius	Zero-Turn
Transmission	Hydrostatic
Cutting Height	1.5 to 4.5 inches
Fuel Capacity	3 gallons
