Operation
13
Setting the Height-of-Cut
The height-of-cut lever (deck lift) is used to raise and
lower the mower to the desired cutting height.
1. The cutting height may be set in one of seven
positions from approximately 1-1/2 to 4-1/2
inches (38 to 116 mm).
2. Pull on the height-of-cut lever (deck lift) and
move it to the desired position (Fig. 8).
1
4-1/2” (116mm)
1–1/2” (38 mm)
2” (51 mm)
2–1/2” (64 mm)
3” (76 mm)
3–1/2” (89 mm)
4” (102 mm)
Approximately

Figure 8
1. Height-of-cut lever (deck lift)
Positioning the Seat
The seat can move forward and backward. Position
the seat where you have the best control of the
machine and are most comfortable.
1. Raise the seat and loosen the adjustment knob
(Fig. 9).
2. Move the seat to the desired position and tighten
the knob.
1

Figure 9
1. Adjustment knob

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Toro Wheel Horse 16-44 HXL and is the answer not in the manual?

Toro Wheel Horse 16-44 HXL Specifications

General IconGeneral
Horsepower16 HP
Cylinders2
TransmissionHydrostatic
Drive2WD
Cutting Width44 inches
Blades2
Turning Radius18 inches
Deck MaterialSteel
Fuel Tank Capacity3 U.S. gallons
