Installation
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
Description
Qty.
Use
Nopartsrequired
–
Preparethemachineforinstallation.
Nopartsrequired
–
Removetheplasticcargobed.
Flatbed1
Footrest1
Carriagebolt(3/8x3inches)
10
Hexnut(3/8inch)
17
Button-headscrew(3/8x1inch)
7
Rear-seathandle1
Hold-downstrap1
Countersunkscrew(1/4inch)
2
Locknut(1/4inch)
2
Siderail
2
Rivet10
Rubbergrommet8
Installtherear-facingseat.
Nopartsrequired
–
Foldtherear-facingseat(whendesired).
Decal120-06252
Decal138-55542
Applythedecals.
PreparingtheMachine
1.Parkthemachineonalevelsurface.
2.Engagetheparkingbrake.
3.Shutofftheengineandremovethekey.
g038447
Figure1
