UsingtheSideDischarge
Themowerhasahingedgrassdeectorthat
dispersesclippingstothesideanddowntowardthe
turf.
DANGER
Withoutagrassdeector,dischargecover,or
acompletegrass-catcherassemblymounted
inplace,youandothersareexposedtoblade
contactandthrowndebris.Contactwith
rotatingmowerblade(s)andthrowndebris
willcauseinjuryordeath.
•Neverremovethegrassdeectorfromthe
mowerdeckbecausethegrassdeector
routesmaterialdowntowardtheturf.Ifthe
grassdeectoriseverdamaged,replaceit
immediately.
•Neverputyourhandsorfeetunderthe
mowerdeck.
•Nevertrytoclearthedischargearea
ormowerbladesunlessyoumovethe
blade-controlswitch(PTO)totheOFF
position,rotatethekeyswitchtotheOFF
position,andremovethekeyfromthekey
switch.
•Makesurethatthegrassdeectorisinthe
downposition.
AdjustingtheHeightofCut
UsingtheTransportLock
1.Pushonthedeck-liftpedalusingyourfootto
raisethemowerdeck(Figure33).
2.Pushthetransport-lockleverforwardtounlock
thetransportlock;pushthetransport-locklever
rearwardtolockthetransportlock(Figure33).
g336604
Figure33
1.LOCKposition—the
mowerdecklocksinto
thetransportposition.
3.Pushonthedeck-liftpedal
usingyourfoottoraisethe
mowerdeck.
2.UNLOCKposition—the
mowerdeckdoesnotlock
intothetransportposition.
30
