thelever,allowthereverse-indicatorspringsto
bringtheleversbacktoneutral.
Note:Thewheelsmuststopturningorslightly
creepinreverse.
11.Shutofftheunit,removethejumperwirefrom
thewireharness,andplugtheconnectorinto
theseatswitch.
12.Removethejackstands.
13.Raisethedeckandinstalltheheight-of-cutpin.
14.Checkthatthemachinedoesnotcreepin
neutralwiththeparkbrakesdisengaged.
Adjustingthe
Motion-ControlDamper
Youcanadjustthetopdamper-mountingbolttoobtain
amoredesiredmotion-controlleverresistance.See
Figure84formountingoptions.
g008620
Figure84
Rightmotioncontrolshown
1.Torquethelocknutto23N∙m(17ft-lb).Theboltmust
protrudepasttheendofthelocknutaftertorquing.
2.Mostresistance(rmestfeel)
3.Damper
4.Mediumresistance(mediumfeel)
5.Leastresistance(softestfeel)
Adjustingthe
Motion-Control
Neutral-LockPivot
Youcanadjusttheangednuttoobtainthedesired
motion-controlleverresistancewhenmovingittothe
neutral-lockposition.SeeFigure85foradjustment
options.
1.Loosenthejamnut.
2.Tightenorloosentheangednuttothedesired
feel.
Note:Formoreresistance,tightentheanged
nut.Forlessresistance,loosentheangednut
3.Tightenthejamnut.
g008621
Figure85
1.Flangednut2.Jamnut
56
