NOTE:
Before tightening, make sure
wheel contacts floor. Wheel
may have to be re-adjusted
if door is difficult to open
and close.
31 30
7
5
25
22
3/8 X 2-1/2" (64mm)
STEP 17
SECURELY
tighten all bolt connections in this step.
