NOTE:
Before tightening, make sure
wheel contacts floor. Wheel
may need to be re-adjusted
if door is difficult to open
and close.
30
31
5
7
22
3/8 X 2-1/2" (64mm)
29
23
SECURELY
tighten all bolt connections in this step.
STEP 18
