Torque X-CREATE WALL SPACE - Page 13

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-8U (2)
1/2 X 4-1/4" BOLT (20)
1/2" FLAT WASHER (40)
1/2" LOCK NUT (20)
XCREATE-4SB (2)
13
STALL BAR MODULE
NOTE:
If more modules will be assembled, do not tighten bolts at this time.
