Torque X-CREATE WALL SPACE - Endless Rope Drum (Upright): Pages

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
1/2 X 1-1/4"
HEX BOLT (4)
1/2" FLAT
WASHER (4)
1/2" FLANGE
NUT (4)
CONNECTOR
BRACKET
(VERTICAL)
NOTE:
THIS BOLT MUST BE ASSEMBLED
FROM THIS DIRECTION
ENDLESS ROPE DRUM
NOTE:
SECURELY tighten bolt connections in this step.
41
XERD
ENDLESS ROPE DRUM (VERTICAL MOUNT)
