Torque X-CREATE WALL SPACE - Resistance Band Anchor

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-8U
NOTE:
MAKE SURE TO USE
PRE-INSTALLED SPACER
XCREATE-RBA
XCREATE-4SX
1/2 X 1" BOLT (2)
PRE-INSTALLED
1/2 FLAT WASHER (2)
PRE-INSTALLED
1/2 X 4-3/4" BOLT
PRE-INSTALLED
1/2" FLAT WASHER (2)
PRE-INSTALLED
1/2" LOCK NUT
PRE-INSTALLED
38
XCREATE-RBA
RESISTANCE BAND ANCHOR
NOTE:
SECURELY tighten bolt connections in this step.
