Torque X-CREATE WALL SPACE - Page 37

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-BT
BALL TARGET
EXTENSION
1/2 X 4" BOLT (2)
1/2" FLAT WASHER (4)
1/2" LOCK NUT (2)
37
XCREATE-BT
BALL TARGET
NOTE:
After this step has been completed, SECURELY
tighten all bolt connections from the last two steps.
