NOTE:
X-CREATE Wall Space Systems can be customized in countless ways. This
manualprovides instructions for assembling base units, module options and
attachment options. If you worked with Torque X-Team Design during the
purchasing process, please request a Bill of Material Drawing to reference your
exact set-up. For assistance, contact
www.sales@torquefitness.com
or call
(763) 754-7533; Toll free in USA (877) 867-7854.
NOTE:
When assembling any X-CREATE System that is longer than one module wide,
the hardware will shared between two side by side modules and pull-up bars.
It is recommended to keep all bolt connections loose until the base system and
all of the module stations have been assembled. Securely tighten all frame
connections at this time, and then proceed to the attachment options.
Attachment options can be securely tightened as they are assembled.
TOOLS FOR ASSEMBLY:
3/8" ALLEN WRENCH
•
5/16" ALLEN WRENCH
•
3/16" ALLEN WRENCH
•
3/4" WRENCH OR SOCKET
•
9/16" WRENCH OR SOCKET
•
1/2" WRENCH OR SOCKET
•
RUBBER MALLET
•
TABLE OF CONTENTS
ONE MODULE ASSEMBLY:
PAGE 3
1.
MODULE ASSEMBLY
2.
8' UPRIGHT EXTENSION MODULE:
PAGE 6
•
STORAGE MODULE:
PAGES 8-11
•
STALL BAR MODULE:
PAGE 13
•
BALL & HANGING STORAGE MODULE:
PAGES 15-18
•
BALL TARGET WALL MODULE:
PAGE 20
•
8' OLYMPIC LIFTING STATION MODULE:
PAGES 22-25
•
ATTACHMENT ASSEMBLY
3.
BALL & HANGING STORAGE EXTENSION:
PAGE 28
•
BATTLE ROPE ANCHOR:
PAGE 29
•
HANGING STORAGE HOOK:
PAGE 30
•
DOUBLE PLAY:
PAGE 31
•
HORIZONTAL MOUNT GROUND ROTATIONAL TRAINER:
PAGE 32
•
3-DIMENSIONAL SWIVEL:
PAGES 33-34
•
BALL TARGET:
PAGES 35-37
•
RESISTANCE BAND ANCHOR:
PAGE 38
•
VERTICAL DUMBBELL RACK 4 PAIR:
PAGE 39
•
ENDLESS ROPE DRUM (UPRIGHT):
PAGES 40-41
•
ATTACHMENT ANCHOR:
PAGE 42
•
DIP ATTACHMENT:
PAGE 43
•
PLYO STEP:
PAGE 44
•
ANCHORING:
PAGE 45
4.
URETHANE BOOT:
PAGE 46
5.
WARNING!
ALL X-CREATE ARE REQUIRED TO BE ANCHORED TO THE
FLOOR TO PREVENT ROCKING OR TIPPING DURING USE.
2
