Torque X-CREATE WALL SPACE - Page 16

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
RAIL (2)
END BRACKET (2)
3/8 X 1-1/4" BOLT (4)
3/8" FLAT WASHER (4)
NOTE:
RAILS ARE ASSEMBLED
FOR STABILITY BALL WIDTH.
RAILS CAN BE BOLTED TO
NARROWER HOLES FOR
SMALLER ACCESSORIES
NOTE:
LOOSELY assemble bolt connections in this step.
BALL & HANGING STORAGE MODULE
16
