Torque X-CREATE WALL SPACE - Urethane Boots

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
FRONT BOOT
1/4" FLAT WASHER
1/4 X 3/8" BOLT
XCREATE-8U
1-3/4"
FRONT BOOT
2-3/4"
REAR BOOT
46
URETHANE BOOTS
NOTE:
The URETHANE BOOTS and hardware are packaged with the
upright boxes
SECURELY tighten bolt connections in this step.
Repeat this step for every upright.
