Torque X-CREATE WALL SPACE

To Next Page

To Previous Page

50 180

190150 170160

130 14012090 110100403010 706020 80

1 2 4 5 7

200

XCREATE-8U

XCREATE-4SX

NOTE:

MAKE SURE TO USE PRE-

INSTALLED SPACERS (4)

NOTE:

REMOVE END CAP

PRIOR TO ASSEMBLY.

RE-ATTACH END CAP

AFTER ASSEMBLY (2)

1/2 X 4-3/4" BOLT (4)

PRE-INSTALLED

1/2" FLAT WASHER (8)

PRE-INSTALLED

1/2" LOCK NUT (4)

PRE-INSTALLED

8' UPRIGHT EXTENSION MODULE

NOTE:

LOOSELY

assemble bolt connections in this step.

Repeat this step for as many modules there are to assemble.

Torque X-CREATE WALL SPACE - Page 6
