Torque X-CREATE WALL SPACE - Page 8

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
1/2" LOCK NUT (16)
1/2" FLAT WASHER (32)
1/2 X 4-1/4"
BOLT (16)
XCREATE-8U (2)
XCREATE-4AT (4)
NOTE:
LOOSELY assemble bolt connections in this step.
8
STORAGE MODULE
