toscano TPM7-POOL - Module Overview; Terminals Description; Pilot Lights Explanation

ENGLISH ( EN )
12
1. MODULE OVERVIEW
ON
OFF
ON
OFF
ON
OFF
AUX
push to
reset
push>4s
man
1
2
A
B
C
D E
2
3
4
5
1
F G H
7
6
Terminals
A. Tranformer current input (In>14A)
B. Heating pump relay input and/or
external temperature sensor
C. Lighting control input
D. Filtration control input
E. Auxiliary relay output (free potential)
F. Lighting supply output
G. Pump supply output
H. Power supply 230V input
91
73
mm
mm
53
mm
Pilots lights
1. Lighting program.
2. Auxiliary output
3. Current time
4. Alarm / Calibration
5. Filtration program 1 (ON/OFF)
6. Filtration program 2 (ON/OFF)
7. Pump running
