ENGLISH ( EN )
20
10. TECHNICAL SPECIFICATIONS
Power supply 230VAC - 50/60Hz
Pump output
14A, 230VAC
Lighting output
230VAC / 5A | 12 VAC / 50W | 12VAC / 100W | 12VAC / 300W
Auxiliary relay
(free voltage)
250V/5A max.
Max. terminal
cross-section
(power / control)
4mm2 / 2,5mm2
Temperature
-10º...+55º C
Directives
| - 2016 - | D.C. 2014 / 30 / CE | EMC |
| D.C. 2014 / 35 / UE | C.E.
| ROHS | EN61558 |
9. BLUETOOTH / WIFI CONNECTION
RJ11 connector
TPM7-POOL is a model to which an external Tpool-B or Tpool-W communications
module can be optionally connected via the RJ11 connector. As external communication
modules, the range of the equipment is considerably improved.
TPOOL-B
ON
OFF
ON
OFF
ON
OFF
AUX
push to
reset
push>4s
man
TPM7 POOL
1
2
