Toshiba 40L345 DB User Manual

English - 46 -
English
Specications and Accessories
Broadcast Systems/Channels
DVB-T MPEG2, DVB-T MPEG4 HD, DVB-T2
DVB-C MPEG2, DVB-C MPEG4
Video Input PAL, SECAM, NTSC 4.43
Stereo Nicam
External Connections
1-SCART 1 Input 21-pin SCART RGB, A/V
2-SCART-S (via SCART 1) Input 21-pin SCART S-Video
3-YPbPr (via VGA) Input Mini D-Sub 15-Pin Analogue
4-SIDE AV Input Side AV Cable input Video + Audio L + R
5-HDMI 1/2 /3 Input Type A
6-PC Input Mini D-Sub 15-Pin Analogue RGB Signal
7-Digital Audio Output S/PDIF (Coaxial)
8-YPbPr Input YPbPr Connection Jack
9-LAN port RJ-45
USB Ports Media Browser Interface Version: USB 2.0
USB Class: Mass Storage
File System: FAT32
For sets with built in wireless unit
the Home network with a wireless
router must be compatible with; IEEE 80211 a/b/g/n
Security Protocols WEP 64/128, WPA, WPA2, TKIP, AES, WAPi.
USB 2.0
Headphone Socket 3.5mm stereo
Operating Conditions Temperature 5°C - 35°C (41°F - 94°F)
Humidity 20 - 80% (non-condensing)
Supplied Accessories Remote Control
2 batteries (AAA,IEC R03 1.5V)
Four screws
Side AV cable
YPbPr Connection Cable
Stand xing cover
P Clip
Optional Accessories Wireless USB Adaptor - Toshiba WLM -30U2 and is available from the retail
outlet or Toshiba service company.
40” L
Energy Efciency Class
A
Visible Screen Size (approx.)
102 cm / 40”
On Mode Power Consumption (approx.) (*)
62 W
Annual Power Consumption (approx.) (**)
90 kWh
Standby Power Consumption (approx.)
< 0.50 W
Screen Resolution (pixels)
1920 x 1080
Display
16:9
Sound Output (at 10% distortion)
2 x 8
Power Consumption Model (approx.)
100 W
Weight TV with stand
13.5 kg
Gross weight
17.0 kg
TV without stand
10.0 kg
(*) Tested in accordance with IEC 62087-BD in default settings.
(**) Energy consumption 90 kWh per year, based on the power consumption of the television operating 4 hours per day for
365 days. The actual energy consumption will depend on how the television is used.
A (mm) B (mm) C (mm) D (mm) E (mm) F (mm) G (mm)
40L345*DB 932.83 560.23 249.00 107.00 602.80 200.00 200.00
Specication is subject to change without notice.
