Toshiba BMS-TP0641ACE User Manual

EN-14
HOW TO OPERATE (continued)
Monitoring Air Conditioners (continued)
<Choose an area from tenant by block>
A Select [MAIN].
B Select [Whole Bldg].
Choose a block to which tenants belong.
C Select [TENANT].
Choose a tenant.
D Select [AREA].
E Choose an area whose air-conditioning state
you want to check.
Fig. 3-4 Areas by Block/Tenant
4
Monitoring screen by unit
<Choose an air conditioner from block>
A Select [MAIN].
B Select [Whole Bldg].
Choose a block.
C Select [UNIT].
D Choose an air conditioner whose state you want
to check.
Fig. 4-1 Units by Block
<Choose an air conditioner from tenant by
block>
A Select [MAIN].
B Select [All Tenants].
Choose a tenant.
C Select [UNIT].
D Choose an air conditioner whose state you want
to check.
Fig. 4-2 Units by All Tenants
B DE
C
A
B
D
A
C
B
D
A
C
