314
10.WHEN THIS MESSAGE APPEARS
10
2. “Check staple cartridge in the Saddle Stitch Unit”
This message will be shown only if the Saddle Stitch Finisher (optional) is installed. When the staples in
the stapler of the Saddle Stitch Finisher run out, this message appears.
Replace the staple cartridge according to the following procedure.
1
Open the front cover of the finisher.
2
Slide the Saddle Stitch Unit carefully
toward the front.
3
Pull the handle of the stapler of the Sad-
dle Stitch Unit toward you to unlock it.
Then turn the stapler clockwise for about
60 degrees.
• The stapler will be locked and will not be turned any further
when it becomes almost horizontal.
1
2
To Next Page
