1.TROUBLESHOOTING FOR THE HARDWARE
Clearing a Paper Misfeed 25
1 TROUBLESHOOTING FOR THE HARDWARE
29
Close the paper exit cover of the saddle stitch unit and the lower cover of the Saddle
Stitch Finisher.
Paper misfeed inside of the equipment
Be careful not to let your fingers be caught between the equipment and the External Large Capacity Feeder.
28
Remove the misfed paper.
30
Connect the finisher to the equipment.
Connect the finisher with the equipment while pressing the lock lever.
Place your hand on portion A in the figure and then move the finisher
carefully.
Be careful not to let your fingers be caught between the
finisher and the equipment.
A
1
When the External Large Capacity Feeder (optional)
is installed, operate the lever on the External Large
Capacity Feeder and separate it from the equipment.
2
Open the paper feeder cover on the lower right of the
equipment.
To Next Page
