1 TROUBLESHOOTING FOR THE HARDWARE
38 Clearing a Staple Jam
11
Make sure of the following two requirements before test stapling:
y The Saddle Stitch Finisher is securely attached to the equipment.
y A3, B4, A4-R, LD, or LT-R paper is set in the drawer.
6
Remove the jammed staples.
7
Push the knob to lower the shutter.
Check that the shutter is securely held by the latch of the green lever.
8
Fit the staple cartridge.
Insert each cartridge until it is fixed with a click.
9
Unlock the stapler by pulling its handle toward you.
Then return the stapler to its original position.
10
Carefully insert the saddle stitch unit into the finisher.
2
1
To Next Page
