WAVEFORMS
The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
NOTE:
H-3
CRT
POWER
48
49
47
45
46
POWER ON
20µs
5.0V
POWER ON
20µs
50V
POWER ON
20µs
50V
STANDBY
5µs
5.0V
STANDBY
5µs
5.0V
