ELECTRICAL REPLACEMENT PARTS LIST
Location No. TSB P/N Reference No. Description
RESISTORS
! R401 AE005693 R3K58A331J R,METAL OXIDE 330 OHM 2W
! R402 AE005729 R3K58A151J R,METAL OXIDE 150 OHM 2W
! R408 AE006276 R3K58AR68J R,METAL OXIDE 0.68 OHM 2W
! R418 BZ210052 R002T21R8J RC 1.8 OHM 1/2W
R427 AE000145 R002T2561J RC 560 OHM 1/2W
! R444 AE005734 R4K1T4562F R,METAL 1 5.6K OHM 1/4W
! R445 AD302182 R002T4153J RC 15K OHM 1/4W
! R447 BZ210021 R65582680J R,FUSE 68 OHM 1/2W
R448 AE005687 R3K581102J R,METAL OXIDE 1K OHM 1W
R450 AE007185 R3K58B6R8J R,METAL OXIDE 6.8 OHM 3W
! R803 AE006275 R3K58A153J R,METAL OXIDE 15K OHM 2W
! R805 AE006275 R3K58A153J R,METAL OXIDE 15K OHM 2W
! R807 AE006275 R3K58A153J R,METAL OXIDE 15K OHM 2W
R3012 AE006273 R3K5811R8J R,METAL OXIDE 1.8 OHM 1W
! R3803 BZ210206 R002T2155J RC 1.5M OHM 1/2W
! R3806 BZ210080 R0G3K2275K RC 2.7M OHM 1/2W
! R3812 AE005868 R3K581331J R,METAL OXIDE 330 OHM 1W
! R3817 BZ210094 R5X2CD010J R,CEMENT 1 OHM 5W
! R3821 AE005690 R3K581R33J R,METAL OXIDE 0.33 OHM 1W
! R3828 AE005735 R63881R22J R,FUSE 0.22 OHM 1W
CAPACITORS
C313 BZ110101 E5EZF3222M CE 2200 UF 25V
! C402 BZ110195 E02LU8220M CE 22 UF 100V
! C403 BZ110016 E5EZT2471M CE 470 UF 16V
! C407 BZ210176 E02LF3222M CE 2200 UF 25V
C423 AD301144 P4J7F3274J CMPP 0.27 UF 250V PMS
! C428 BZ110218 P4N8FJ103H CMPP 0.01 UF 1.25KV
C431 BZ110204 E0ELFD220M CE 22 UF 250V
C450 BZ110182 C03L0R713K CC 0.001 UF 2KV R
C802 BZ110247 C0JBB0713K CC 0.001 UF 2KV B
! C3801 AE003965 P2122B334M CMP 0.33 UF 275V ECQUL
C3811 AE000874 C0PLRR7E3K CC 0.0015 UF 2KV R
! C3815 BZ110012 E51CGC471M CE 470 UF 200V
! C3816 AE002878 CD39E0MQ3M CC 0.0047UF 250V
C3818 BZ110101 E5EZF3222M CE 2200 UF 25V
! C3820 BZ110188 E50HU5100M CE 10 UF 50V
! C3822 BZ110129 E5EZF2222M CE 2200 UF 16V
! C3823 BZ110032 E5EZF3102M CE 1000 UF 25V
! C3826 BZ110130 E62NFC221M CE 220 UF 200V
C3827 BZ110101 E5EZF3222M CE 2200 UF 25V
DIODES
D101 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D102 BZ410021 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
D103 BZ410021 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
D105 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D106 AD300070 D97U01201B DIODE,ZENER MTZJ12B T-77
D107 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D401 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC
! D402 AD300731 D2WXN49370 DIODE,SILICON 1N4937
D403 BZ410019 D97U03001B DIODE,ZENER MTZJ30B T-77
D404 BZ410019 D97U03001B DIODE,ZENER MTZJ30B T-77
D405 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC
D406 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC
D408 BZ410037 D97U03301B DIODE,ZENER MTZJ33B T-77
D409 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D410 BZ410022 D97U06R81B DIODE,ZENER MTZJ6.8B T-77
D411 AD300731 D2WXN49370 DIODE,SILICON 1N4937
D413 AD300731 D2WXN49370 DIODE,SILICON 1N4937
D414 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC
! D416 BZ410020 D97U05R11B DIODE,ZENER MTZJ5.1B T-77
D603 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC
D613 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D801 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D802 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D803 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D2201 BZ410087 0021E2Q140 LED LTL-1CHEE-002A
D2303 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D2304 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D3003 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3005 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC
D3006 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC
J3-1
To Next Page
