Toshiba MD14F11 Service Manual

ELECTRICAL REPLACEMENT PARTS LIST
Location No. TSB P/N Reference No. Description
DIODES
D3007 BZ410021 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
D3008 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC
D3009 BZ410090 D97U04R71B DIODE,ZENER MTZJ4.7B T-77
D3010 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3011 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3801 BZ410021 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
D3802 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3803 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3804 AD300671 D97U01801B DIODE,ZENER MTZJ18B T-77
D3805 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3806 AE006060 D28T0ERB20 DIODE,RECTIFIER 10ERB20-TA1B2
D3807 AD300731 D2WXN49370 DIODE,SILICON 1N4937
! D3808 BZ410062 D2WTRM11C0 DIODE,SILICON RM11C-EIC
! D3809 BZ410062 D2WTRM11C0 DIODE,SILICON RM11C-EIC
D3810 AD300671 D97U01801B DIODE,ZENER MTZJ18B T-77
D3811 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
! D3815 BZ410062 D2WTRM11C0 DIODE,SILICON RM11C-EIC
! D3816 BZ410062 D2WTRM11C0 DIODE,SILICON RM11C-EIC
! D3817 AE002498 D2LKB340F0 DIODE,SCHOTTKY SB340FL-6737
! D3818 AD300731 D2WXN49370 DIODE,SILICON 1N4937
! D3819 BZ410010 D28T21DQN9 DIODE,SCHOTTKY 21DQ09N-TA2B1
! D3820 BZ410010 D28T21DQN9 DIODE,SCHOTTKY 21DQ09N-TA2B1
! D3821 BZ410080 D2WXRU2AM0 DIODE,SILICON RU2AM-EIC
D3822 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
! D3823 AE002498 D2LKB340F0 DIODE,SCHOTTKY SB340FL-6737
D3826 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3827 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3828 BZ410067 D97U02R21B DIODE,ZENER MTZJ2.2B T-77
! D3830 BZ410010 D28T21DQN9 DIODE,SCHOTTKY 21DQ09N-TA2B1
D3831 BZ410064 D97U03R91B DIODE,ZENER MTZJ3.9B T-77
D4001 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D4002 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D4003 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D4004 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D4005 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D8101 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D8111 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D8112 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
ICS
IC101 AE006062 I55D06084A IC OEC6084A
IC103 AD301641 I9UF032310 IC PST3231NR
IC199 AE006272 A5S001ND25 INIT DATA BR24L04F-WE2
! IC302 AD302184 I0FSP7522N IC AN7522N
! IC401 BZ611053 I01TD55220 IC AN5522
IC601 AE004116 I03FC319N0 IC LA76319NM-MPB-E
IC902 BZ611068 I01FF58290 IC AN5829S-E1V
IC2301 AE003581 I03F065650 IC LA6565-TE-L-E
IC2304 AE005769 I07J003580 IC BA10358FV-E2
! IC3001 BZ611015 I1KA97805A IC KIA7805API
IC3002 BZ611015 I1KA97805A IC KIA7805API
IC3005 BZ611033 I1KA97809A IC KIA7809API
! IC3800 AE002809 000220002W PHOTO COUPLER PS2561AL1-1-V(W)
IC4001 AE005760 ICQK068620 IC ZR36862PQCG
IC4002 AE005421 I57J0L02F0 IC BR24L02F-WE2
IC4003 AE006061 I07F9E00W0 IC BA33E00WHFP-TR
IC4007 AE007368 S5R801VF05 MEMORY DATA SST39VF800A-70-4C-EKE
IC4008 AE005483 ICLJ0610EX IC HY57V161610ETP-7
IC4009 AE005483 ICLJ0610EX IC HY57V161610ETP-7
IC4201 AE001295 I0QJ045800 IC NJM4580M(TE1)
IC8102 AE003584 I17F017530 IC PCM1753DBQR
TRANSISTORS
Q101 AE005872 T6RA015300 TRANSISTOR,SILICON 2SA1530A-T1
Q105 AE005873 T8RA030520 TRANSISTOR,SILICON 2SC3052-T1
Q301 AE005873 T8RA030520 TRANSISTOR,SILICON 2SC3052-T1
Q302 AE005873 T8RA030520 TRANSISTOR,SILICON 2SC3052-T1
Q305 AE005873 T8RA030520 TRANSISTOR,SILICON 2SC3052-T1
! Q401 BZ510004 TA3T016240 TRANSISTOR,SILICON 2SA1624-AA
! Q405 BZ510097 TCAT03227Y TRANSISTOR,SILICON KTC3227_Y-AT
! Q406 AE000656 TC1G058850 TRANSISTOR,SILICON 2SC5885
Q601 AE005873 T8RA030520 TRANSISTOR,SILICON 2SC3052-T1
Q602 AE005873 T8RA030520 TRANSISTOR,SILICON 2SC3052-T1
