ELECTRICAL REPLACEMENT PARTS LIST
Location No. TSB P/N Reference No. Description
TRANSISTORS
Q605 AE005941 TPRAB05002 COMPOUND TRANSISTOR RT1P141C-T112-1
! Q804 BZ510009 TC3F042170 TRANSISTOR,SILICON 2SC4217(D,E)-RAC
! Q805 BZ510009 TC3F042170 TRANSISTOR,SILICON 2SC4217(D,E)-RAC
! Q806 BZ510009 TC3F042170 TRANSISTOR,SILICON 2SC4217(D,E)-RAC
Q2201 AE005938 TNRAC05003 COMPOUND TRANSISTOR RT1N241C-T1
Q2301 BZ510112 T67J1036K0 TRANSISTOR,SILICON 2SA1036KT146
Q2302 AE003592 T67J048TL0 TRANSISTOR,SILICON 2SA2048TL
Q2303 BZ510109 TCAA3875SY TRANSISTOR,SILICON KTC3875S_Y_RTK
Q2304 BZ510109 TCAA3875SY TRANSISTOR,SILICON KTC3875S_Y_RTK
Q2305 BZ510109 TCAA3875SY TRANSISTOR,SILICON KTC3875S_Y_RTK
Q3000 BZ510057 TAAT01281Y TRANSISTOR,SILICON KTA1281_Y
Q3001 AE005876 TNRAB05004 COMPOUND TRANSISTOR RT1N141C-T1
! Q3003 AD301780 TCA0043690 TRANSISTOR,SILICON KTC4369(O,Y)
Q3004 BZ510057 TAAT01281Y TRANSISTOR,SILICON KTA1281_Y
Q3005 BZ510105 TCAT03209Y TRANSISTOR,SILICON KTC3209_Y-AT
Q3006 BZ510070 TCAT032034 TRANSISTOR,SILICON KTC3203_Y-AT
Q3007 AE005873 T8RA030520 TRANSISTOR,SILICON 2SC3052-T1
Q3008 BZ510070 TCAT032034 TRANSISTOR,SILICON KTC3203_Y-AT
Q3009 BZ510105 TCAT03209Y TRANSISTOR,SILICON KTC3209_Y-AT
Q3010 BZ510057 TAAT01281Y TRANSISTOR,SILICON KTA1281_Y
Q3800 BZ510069 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR)
Q3802 BZ510070 TCAT032034 TRANSISTOR,SILICON KTC3203_Y-AT
! Q3803 AE002251 T25F035630 FET 2SK3563(ORION_Q)
Q4004 BZ510109 TCAA3875SY TRANSISTOR,SILICON KTC3875S_Y_RTK
Q4201 AE005873 T8RA030520 TRANSISTOR,SILICON 2SC3052-T1
Q4203 AE005939 TNRAD05002 COMPOUND TRANSISTOR RT1N441C-T1
Q4209 AE005938 TNRAC05003 COMPOUND TRANSISTOR RT1N241C-T1
Q4210 AE005940 TPRAA05002 COMPOUND TRANSISTOR RT1P431C-T112-1
Q4211 AE005873 T8RA030520 TRANSISTOR,SILICON 2SC3052-T1
Q4212 AE005873 T8RA030520 TRANSISTOR,SILICON 2SC3052-T1
Q8101 BZ510021 TNYJC05001 COMPOUND TRANSISTOR DTC124EKAT146
COILS &TRANSFORMERS
L001 BZ310005 02167D101K COIL 100 UH
L101 AE004117 021JX6560K COIL 56 UH
L401 BZ310004 021679472K COIL 4.7 MH
L402 BZ310063 022100027A COIL,LINEARITY ELH5L4113
L601 BZ310041 02167F101J COIL 100 UH
L602 BZ310005 02167D101K COIL 100 UH
L801 AD301781 021673560K COIL 56 UH
L902 BZ310041 02167F101J COIL 100 UH
L904 BZ310041 02167F101J COIL 100 UH
L3000 AD301785 02167E100K COIL 10 UH
L3001 AD301785 02167E100K COIL 10 UH
! L3800 BZ310116 028R140023 COIL,DEGAUSS 8R140023
! L3801 AE006198 029X000131 COIL,LINE FILTER SS26V-R150162
L3803 AD301539 02AHB0A0A4 CORE,FERRITE W5T_20X10X10A
L4001 BZ310191 02167F2R2J COIL 2.2 UH
L4002 BZ310118 02AHB9A972 CORE,FERRITE W5T29X7.5X19
L4201 BZ310041 02167F101J COIL 100 UH
L4202 BZ310041 02167F101J COIL 100 UH
L8102 AE000828 02167F1R0K COIL 1 UH
L8103 AE000828 02167F1R0K COIL 1 UH
T401 BZ310157 045009003J TRANS,HORIZONTAL DRIVE ETH09K14BZ
! T3800 AD302185 0481300054 TRANSFORMER,SWITCHING 81300054
JACKS
! J801 BZ614434 066F120018 SOCKET,CATHODE RAY TUBE ISMS01S
! J2201 AE003431 060J131016 HEADPHONE JACK MSJ-2000_AG
J2202 AE002949 060J421036 RCA JACK MTJ-032-05A-30-FE
J2203 AE002950 060J421037 RCA JACK MTJ-032-05A-32-FE
J2204 AE002951 060J421030 RCA JACK MTJ-032-05A-31-FE
J4201 AE003568 060J401102 RCA JACK MSP-251V-05NI-FE-LF
SWITCHES
SW2213 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2214 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2215 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2216 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2217 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2218 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2219 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2220 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2221 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
J3-3
To Next Page
