ELECTRICAL REPLACEMENT PARTS LIST
Location No. TSB P/N Reference No. Description
SWITCHES
SW2223 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
VARIABLE RESISTORS
VR401 BZ210255 V1K62H3BT8 VOLUME,SEMI FIXED NVG6THTB222
VR3800 BZ210265 V1K63Q2BTE VOLUME,SEMI FIXED NVG6TLTAB471
P.C.BOARD ASSEMBLIES
PCB110 AE006269 A5S001N110L PCB ASS'Y CCD006A
PCB130 AE007369 A5S002N130L PCB ASS'Y DMD020B
PCBD20 AE007370 A5S002ND20L PCB ASS'Y CMD010A
MISCELLANEOUS
B301 BZ310129 024HT03564 CORE,BEADS W4BRH3.5X6X1.0
B401 BZ310121 024HT03553 CORE,BEADS W5RH3.5X5X1.0
B2301 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B2302 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B2303 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B2304 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B2305 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B3800 BZ310121 024HT03553 CORE,BEADS W5RH3.5X5X1.0
B4001 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4002 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4003 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4005 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4006 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4007 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4008 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4009 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4010 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4011 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4012 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4013 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4014 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4016 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4018 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4201 BZ310121 024HT03553 CORE,BEADS W5RH3.5X5X1.0
B8103 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
BL001 BZ310014 023C00022A COIL,BALUN HPN-01
BT001 AE000012 1412004008 BATTERY,MANGAN R03(AB)E_2P_G
BT002 AE000012 1412004008 BATTERY,MANGAN R03(AB)E_2P_G
CD301 AE006268 06C3123806 CORD,CONNECTOR C3123806
CD302 AE006268 06C3123806 CORD,CONNECTOR C3123806
CD802 BZ614404 WDL6032038 FLAT CABLE AWM2468 AWG26 6C BLACK 320MM
CD803 BZ614447 WBL6022038 FLAT CABLE AWM2468 AWG26 4C BLACK 220MM
CD805 BZ614175 06CU82039A CORD,CONNECTOR SM1098-009-1A
CP101 BZ614458 069S290629 CONNECTOR PCB SIDE A2001WV2-9P
CP301 AE005936 069W120459 CONNECTOR PCB SIDE 213213102W1
CP302 AE005936 069W120459 CONNECTOR PCB SIDE 213213102W1
CP401 BZ614303 069S450089 CONNECTOR PCB SIDE A1561WV2-A5P
CP801 BZ614269 069S320010 CONNECTOR PCB SIDE A2361WV2-2P
CP806 BZ614058 069W010010 CONNECTOR PCB SIDE 005P-2100
! CD3800 AE005639 1209414909 CORD,AC BUSH 9414909
CD4002 AE006055 06C32B2202 CORD,CONNECTOR C32B2202
CD8101 AE003576 122F0C1602 CORD,JUMPER 2F0C1602
CP2301 AE003571 069GYOT119 CONNECTOR PCB SIDE 09-5000-024-001-001
CP2302 AE005934 069EV53030 CONNECTOR PCB SIDE 00_6232_005_006_800+
CP2303 AE005935 069EV63030 CONNECTOR PCB SIDE 00_6232_006_006_800+
! CP3800 BZ614283 069S420110 CONNECTOR PCB SIDE A1561WV2-2P
CP8001 BZ614214 069S2B0629 CONNECTOR PCB SIDE A2001WV2-11P
CP8002 AD301797 069J7C0029 CONNECTOR PCB SIDE IMSA-9604S-12Z14
CP802A BZ614333 067U006049 WIRE HOLDER B2013H02-6P
CP802B BZ614333 067U006049 WIRE HOLDER B2013H02-6P
CP803A BZ614334 067U004029 WIRE HOLDER B2013H02-4P
CP803B BZ614334 067U004029 WIRE HOLDER B2013H02-4P
CP8101 AE006053 069J7C0589 CONNECTOR PCB SIDE IMSA-9604S-12F
ELD201 BZ614043 124116281A EYE LET XRY16X28BD
ELD202 BZ614044 124120301A EYE LET XRY20X30BD
F3800 BZ614504 081PC05005 FUSE 51MS050L
! FB401 AE006267 043214049F TRANSFORMER,FLYBACK FQI14B007_M
FH3800 AE002634 06710T0009 HOLDER,FUSE EYF-52BCY
FH3801 AE002634 06710T0009 HOLDER,FUSE EYF-52BCY
OS2202 BZ614199 077Q004017 REMOTE RECEIVER PIC-37243SR
! SP351 BZ614200 070C533019 SPEAKER SG04D11BNA
! SP352 BZ614200 070C533019 SPEAKER SG04D11BNA
J3-4
