ELECTRICAL REPLACEMENT PARTS LIST
Location No. TSB P/N Reference No. Description
COILS &TRANSFORMERS
! L3800 BZ310066 028R200024 COIL,DEGAUSS 8R200024
! L3801 AE003611 029X000116 COIL,LINE FILTER SS28V-R20130
L3803 AD301539 02AHB0A0A4 CORE,FERRITE W5T_20X10X10A
L4001 BZ310191 02167F2R2J COIL 2.2 UH
L4002 BZ310118 02AHB9A972 CORE,FERRITE W5T29X7.5X19
L4201 BZ310041 02167F101J COIL 100 UH
L4202 BZ310041 02167F101J COIL 100 UH
L4203 BZ310041 02167F101J COIL 100 UH
L4205 BZ310041 02167F101J COIL 100 UH
L8102 AE000828 02167F1R0K COIL 1 UH
L8103 AE000828 02167F1R0K COIL 1 UH
T401 BZ310172 045013003J TRANS,HORIZONTAL DRIVE ETH14Y47AY
! T3800 AD302030 0481390314 TRANSFORMER,SWITCHING 81390314
JACKS
! J801 AD301356 066F130020 SOCKET,CATHODE RAY,TUBE ISHS53S
! J2201 AE003431 060J131016 HEADPHONE JACK MSJ-2000_AG
J2202 AE002949 060J421036 RCA JACK MTJ-032-05A-30-FE
J2203 AE002950 060J421037 RCA JACK MTJ-032-05A-32-FE
J2204 AE002951 060J421030 RCA JACK MTJ-032-05A-31-FE
J4201 AE003568 060J401102 RCA JACK MSP-251V-05NI-FE-LF
J4203 AE002759 060J431020 RCA JACK MSP-213V2-432_NI_LF
SWITCHES
SW2213 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2214 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2215 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2216 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2217 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2218 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2219 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2220 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2221 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW2223 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
VARIABLE RESISTORS
VR402 BZ210218 V1K63H3BTE VOLUME,SEMI FIXED NVG6TLTAB222
VR3800 BZ210265 V1K63Q2BTE VOLUME,SEMI FIXED NVG6TLTAB471
P.C.BOARD ASSEMBLIES
PCB110 AE006455 A5S102U110 PCB ASS'Y CCE012A
PCB130 AE006456 A5S102U130 PCB ASS'Y DMD020B
PCB250 AE006457 A5S102U250 PCB ASS'Y CME012A
MISCELLANEOUS
B2301 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B2302 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B2303 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B2304 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B2305 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B3001 BZ310121 024HT03553 CORE,BEADS W5RH3.5X5X1.0
B3800 BZ310122 024HT03563 CORE,BEADS W4BRH3.5X6X1.0X2
B4001 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4002 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4003 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4005 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4006 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4007 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4008 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4009 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4010 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4011 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4012 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4013 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4014 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4016 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4018 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
B4201 BZ310121 024HT03553 CORE,BEADS W5RH3.5X5X1.0
B8103 AE005476 0246C51024 CORE,BEADS MMZ1608R102CT
BL001 BZ310014 023C00022A COIL,BALUN HPN-01
BT001 AE005640 141R004016 BATTERY,MANGAN GR03X-SP2
BT002 AE005640 141R004016 BATTERY,MANGAN GR03X-SP2
CD301 AE006268 06C3123806 CORD,CONNECTOR C3123806
CD302 AE006268 06C3123806 CORD,CONNECTOR C3123806
CD801 AE005637 06CH823004 CORD,CONNECTOR CH823004
CD802 AE001076 WDL6044038 FLAT CABLE AWM2468 AWG26 6C BLACK 440MM
J3-4
