ELECTRICAL REPLACEMENT PARTS LIST
Location No. TSB P/N Reference No. Description
MISCELLANEOUS
CD803 AE004016 WBL6036038 FLAT CABLE AWM2468 AWG26 4C BLACK 360MM
CP101 BZ614458 069S290629 CONNECTOR PCB SIDE A2001WV2-9P
CP301 AE005936 069W120459 CONNECTOR PCB SIDE 213213102W1
CP302 AE005936 069W120459 CONNECTOR PCB SIDE 213213102W1
! CP401 BZ614303 069S450089 CONNECTOR PCB SIDE A1561WV2-A5P
CP801 BZ614269 069S320010 CONNECTOR PCB SIDE A2361WV2-2P
! CD3800 AE005639 1209414909 CORD,AC BUSH 9414909
CD4002 AE006055 06C32B2202 CORD,CONNECTOR C32B2202
CD8101 AE003576 122F0C1602 CORD,JUMPER 2F0C1602
CP2301 AE003571 069GYOT119 CONNECTOR PCB SIDE 09-5000-024-001-001
CP2302 AE005934 069EV53030 CONNECTOR PCB SIDE 00_6232_005_006_800+
CP2303 AE005935 069EV63030 CONNECTOR PCB SIDE 00_6232_006_006_800+
! CP3800 BZ614283 069S420110 CONNECTOR PCB SIDE A1561WV2-2P
CP4201 BZ614242 069S260629 CONNECTOR PCB SIDE A2001WV2-6P
CP8001 BZ614214 069S2B0629 CONNECTOR PCB SIDE A2001WV2-11P
CP8002 AD301797 069J7C0029 CONNECTOR PCB SIDE IMSA-9604S-12Z14
CP802A BZ614333 067U006049 WIRE HOLDER B2013H02-6P
CP802B BZ614333 067U006049 WIRE HOLDER B2013H02-6P
CP803A BZ614334 067U004029 WIRE HOLDER B2013H02-4P
CP803B BZ614334 067U004029 WIRE HOLDER B2013H02-4P
CP8101 AE006053 069J7C0589 CONNECTOR PCB SIDE IMSA-9604S-12F
EL001 BZ614044 124120301A EYE LET XRY20X30BD
EL002 BZ614043 124116281A EYE LET XRY16X28BD
! F3800 BZ614504 081PC05005 FUSE 51MS050L
! FB401 AE006458 043220059F TRANSFORMER,FLYBACK FJN20A003_M
FH3800 AE002634 06710T0009 HOLDER,FUSE EYF-52BCY
FH3801 AE002634 06710T0009 HOLDER,FUSE EYF-52BCY
OS2202 BZ614199 077Q004017 REMOTE RECEIVER PIC-37243SR
PH3800 BZ614016 069W01001A CONNECTOR PCB SIDE 003P-2100
PH3801 BZ614016 069W01001A CONNECTOR PCB SIDE 003P-2100
! RY3800 AD300114 0560V20115 RELAY ALKS321
! SP351 AE006459 070N546012 SPEAKER YDP4010-2
! SP352 AE006459 070N546012 SPEAKER YDP4010-2
TM101 AE007371 076D0KG01A TRANSMITTER ORD204N7404831-U
! TU001 AE006069 0163300018 RF UNIT 115-V-KA35ARB
! TH3800 AD302000 D8EE0B1400 DEGAUSS ELEMENT B59203-S1060-B14
! V801 AE005627 0981210456 CRT W/DY A51LYZ095X80
X101 BZ613019 1002T01606 CERAMIC OSCILLATOR CSTLS16M0X53-A0
X601 AD301653 100DT3R531 CRYSTAL HC-49/U
X4001 AD301803 100BT02701 CRYSTAL HC-49U/S
RESISTOR
RC................... CARBON RESISTOR
CAPACITORS
CC................... CERAMIC CAPACITOR
CE................... ALUMI ELECTROLYTIC CAPACITOR
CP................... POLYESTER CAPACITOR
CPP.................. POLYPROPYLENE CAPACITOR
CPL.................. PLASTIC CAPACITOR
CMP................... METAL POLYESTER CAPACITOR
CMPL................ METAL PLASTIC CAPACITOR
CMPP................ METAL POLYPROPYLENE CAPACITOR
J3-5
