19
Push the air filter,
and pull it downward.
Front panel
(Lower)
Air filter knob
Filter holder
High Wall Type
(Model : 1H series)
• Push the projection at the center of air filter. Clip is out.
• Undo the clip of air filter, pull the air filter downward while pushing it
toward the main unit side.
(Model : 2H series)
• Open the air inlet grille.
Lift the air inlet grille up to the horizontal position.
• Take hold of the left and right handles of the air filter and lift it up
slightly, then pull downward to take it out from the filter holder.
NOTE
• For cleaning of air filter, use a cleaner or brush clean. If stain is heavy,
it is effective to wash the air filter in tepid water mixed with neutral detergent.
• After washing, rinse it well, and dry it in the shade.
• Install again the air filter which has been cleaned.
Floor Standing Cabinet Type
• Push down the upper part of the suction port a little, and then pull
toward you to remove it.
• Take out the air filter inside of the suction port.
Floor Standing Concealed Type
• Push down hook of the air filter on the front panel (Lower side).
• Pull the air filter toward you to remove it.
Floor Standing Type
Removal / Attachment of air filter
• Pull the air filter toward you.
• To attach the air filter, insert it into the main body
and push in it.
To Next Page
