5
Air outlet/Air outlet flap
Exchanges the air direction according to
cooling or heating time.
Earth screw
It is prepared in the electric parts box.
Air inlet port
Sucks air inside of the room from here.
Air filter
Removes dirt or dust.
(It is included in the suction port.)
Air outlet port
Drain pan (With drain filter)
This accessory is installed at the local site.
Air filter
Removes dirt or dust.
(It is included in the suction port.)
Air inlet port
Sucks air inside of the room from here.
Earth screw
It is prepared in the electric parts box.
Earth screw
It is prepared in the electric parts box.
Front panel (Lower side)
Vertical flap
The air can be automatically discharged
rightward/leftward at stated periods.
Fixing metal holder
Horizontal flap/Air outlet port
Exchanges the air direction according
to cooling or heating time.
Air filter
Removes dirt or dust.
Air inlet port
Sucks air inside of the room from here.
Fixing metal holder (Right and left)
Drain pan
Water accumulated in the drain pan is
drained from here through the drain pipe.
Air inlet
They are provided at front, rear, left,
and right sides.
Fixing leg
Air outlet (Discharge)
Hot air is discharged when cooling operation is performed.
Cold air is discharged when heating operation is performed.
Power source hole
Refrigerant pipe connecting hole
Connecting valve is included inside here.
Outdoor unit
[Floor Standing Cabinet Type]
[Floor Standing Concealed Type]
[Floor Standing Type]
