What to do if start/stop operation on remote controller is unavailable for Toshiba MMU-AP0244HP1-E Air Conditioner?
If the start/stop operation on the remote controller isn't working, check if the auxiliary unit or remote control is being operated.
What to do if my Toshiba Air Conditioner has no communication from remote controller and network adapter?
Check the check display of the corresponding follower unit.
What to do if my Toshiba MMU-AP0244HP1-E has no communication from outdoor unit?
Check position Trouble on the interface P.C. board or part in which of the header unit.
Why does the compressor of my Toshiba Air Conditioner not operate?
If the compressor isn't operating, ensure that the unit has not been delayed for 3 minutes after the compressor was last turned off.
Why does the outdoor fan of my Toshiba Air Conditioner not rotate, or why does the fan speed change?
If the outdoor fan isn't rotating or its speed changes, it might be because low cooling operation is being controlled.
What does it mean if the float switch operated in my Toshiba Air Conditioner?
If the float switch has been activated, it indicates that indoor overflow was detected.
What does it mean if my Toshiba MMU-AP0244HP1-E system abnormally stopped by input of external error (CN80)?
The system stopped because an external error was input in the indoor unit (Interlock).
What does it mean if communication error occurs between MCU of main motor microprocessors of Toshiba Air Conditioner?
Regular communication between header and follower units in the indoor unit was impossible.
What does it mean if error of indoor AC can was detected on my Toshiba MMU-AP0244HP1-E?
This indicates an Indoor EEPROM error (Other error may be detected).
Details specific warning labels found on the unit and their meanings for safe operation.
Outlines critical safety warnings related to electrical shock, high voltage, and operational hazards.
Provides general warnings for repair work, refrigerant handling, and electrical safety.
Illustrates the electrical connections and components for the indoor unit's wiring system.
Describes the procedure for performing a test run from the remote controller.
Provides a summary of common troubles, their operations, and check items for diagnosis.
Explains how to confirm and check error history from the remote controller display.
Lists check codes, locations, descriptions, and check items for outdoor unit issues.
Outlines procedures for replacing the indoor unit's P.C. board, including data backup and writing.
Details concentration limits for R410A refrigerant and requirements for room installation to prevent suffocation.
General| Cooling Capacity | 2.5 kW |
|---|---|
| Heating Capacity | 3.2 kW |
| Power Supply | 220-240 V, 50 Hz |
| Refrigerant | R32 |
| Energy Efficiency Ratio (Heating) | 4.0 |
| Outdoor Unit Dimensions (WxHxD) | 780 x 550 x 290 mm |
