Toshiba MMY-MAP0802FT8-E - Outdoor Unit Exploded Views and Parts List: T8-E Series; T8-E Series Parts List

32
Model Name MMY- MAP
1201T8-E 1001T8-E 0801T8-E 0601T8-E 0501T8-E
11111
222
22
11122
111
11111
11111
11111
11111
22222
33333
33333
111
11111
22211
22211
22222
222
111
11111
11111
44444
111
111
11
11
33333
11111
11111
11111
111
11111
11111
11111
11111
11111
11111
11111
11111
11111
11111
11111
Location
Part No. Description
No.
1 43146737 Valve, Checked, YCV5P-33GME-1
4 43041781 Compressor, DA421A3FB-23M
5 43041782 Compressor, DA351A3FB-23M
7 43046442 Valve, Packed, 9.52 DIA
8 43146680 Valve, Packed, 12.7
16 43100265 Cabinet, Up
17 43119466 Guard, Fan
25 43120219 Fan, Propeller, DIA 710, ASG
26 4312C004 Motor, Fan, DC280V, MF-230-600-1R
27 43146715 Valve, Checked, BCV-804DY
29 43146736 Valve, Checked, YCV3-22GME-1
30 43146676 Joint, Check
32 43146727 Valve, Gas, DIA 25
39 43146734 Valve, Check, ZGV-S55B-A
40 43146709 Valve, PMV, HAM-BD24TF-1
41 43146708 Coil, PMV, HAM-MD12TF-3
43 4314Q060 Strainer, DIA 12.7, C1220T-H
44 4314Q056 Strainer, DIA 25.4, C1220T-H
46 4314Q052 Strainer, DIA 45, C1220T-H
49 43148202 Tank, Liquid
50 43148192 Separator
63 43149325 Band, Fix, SUS304
64 4314G264 Condenser Assembly, Three Row
65 4314G265 Condenser Assembly, Three Row
66 4314G249 Condenser Assembly, One Row
67 4314G250 Condenser Assembly, One Row
69 43157276 Heater, Case, 29W, AC240V
73 43197175 Nut, Flange, M10, SWCH12R
74 43197176 Washer, SPHC
80 4314Q055 Strainer, DIA 19.05, C1220T-H
81 4314Q057 Strainer, DIA 25.4, C1220T-H
91 43100396 Panel, CGCD2-Z08-C77
92 43100406 Cabinet Assembly, Front, Up
93 43100407 Cabinet Assembly, Back, Up
94 43100408 Cabinet Assembly, Side, Left
95 43100409 Cabinet Assembly, Side, Right
96 43100410 Cabinet Assembly, Front, Down
97 43100411 Cabinet Assembly, Back, Down
721 43031110 Diode, 25A, 600V, *GBPC-2506
722 43155214 Resistor, 1Ω, 20W
723 43158207 Reactor, CH-68
724 4316V362 P.C. Board Assembly, Passive, MCC-1580
