Toshiba MMY-MAP0802FT8-E - Outdoor Unit Control Circuit Configuration; Fan Power P.C. Board (MCC-1439) Diagram

9
CN500
DC330V output for fan IPDU
(Judgemant : DC 180–370V)
DC330V output
(For Comp. IPDU)
AC230V input
+12V
GND
Judgement
+12V terminal 1 – 5
+7V terminal 2 – 5
Communication
between fan IPDU
Communication
betweenI/F and
fan IPDU
( )
4. CONFIGURATION OF CONTROL CIRCUIT
4-1. Outdoor Unit
Power P.C. board for fan (MCC-1439)
