Toshiba MMY-MAP0802FT8-E - Outdoor Unit Exploded Views and Parts List: T8-E Series; T8-E Series Parts List (Continued)

34
Model Name MMY- MAP
1201T8-E 1001T8-E 0801T8-E 0601T8-E 0501T8-E
222
22
22211
22222
22222
77777
33333
111
44444
11
22222
11111
22211
22211
11111
11111
11111
11111
11111
111
22233
11111
33333
11111
22222
66666
44444
22222
66666
Location
Part No. Description
No.
4 43041781 Compressor, DA421A3FB-23M
5 43041782 Compressor, DA351A3FB-23M
12 43049683 Band, DIA 8, EPDM
13 43050407 Thermostat, Bimetal
14 43063317 Holder, Thermostat
28 43146660
Coil, Solenoid, AC220–240V, 50Hz,
VPV-MOAJ510B0
30 43146676 Joint, Check
32 43146727 Valve, Gas, DIA 25
33 43146711 Valve, 2-Way, VPV-122DQ1
35 43146699 Valve, Ball, B5/8F, Rohs
37 43146712 Valve, 2-Way, VPV-303DQ1
38 43146730 Valve, 2-Way, VPV-603DQ2
40 43146709 Valve, PMV, HAM-BD24TF-1
41 43146708 Coil, PMV, HAM-MD12TF-3
49 43148202 Tank, Liquid
50 43148192 Separator
52 43148200 Accumulator, 20L
53 43149377 Sensor Assembly, Low Pressure, 150XA4-L1
54 43149378 Sensor Assembly, High Pressure, 150XA4-H3
55 43149317 Rubber, Supporter, Pipe, DIA 25.4
56 43149318 Rubber, Supporter, Pipe, DIA 19.0
57 43149319 Rubber, Supporter, Pipe, DIA 15.9
58 43149320 Rubber, Supporter, Pipe, DIA 8.0
59 43149321 Rubber, Supporter, Pipe, DIA 6.4
61 43149323 Rubber, Supporter, Pipe, DIA 9.52–12.7
62 43149324 Rubber, Cushion, EPDM
63 43149325 Band, Fix, SUS304
68 43151283 Switch, Pressure, ACB-4UB32W
72 43197184 Bolt, Compressor, M6, SWCH18A
