Toshiba MMY-MAP0802FT8-E - Outdoor Unit Exploded Views and Parts List: T8-E Series; T8-E Series Parts List (Continued)

36
Model Name MMY- MAP
1201T8-E 1001T8-E 0801T8-E 0601T8-E 0501T8-E
11111
222
22
11122
111
11111
22222
33333
33333
111
44444
11
22222
11111
11111
22211
22222
222
22
111
11
11111
11111
11111
11111
11111
11111
111
111
11
11
22222
11111
11111
11111
33333
11111
111
11
Location
Part No. Description
No.
1 43146737 Valve, Checked, YCV5P-33GME-1
4 43041781 Compressor, DA421A3FB-23M
5 43041782 Compressor, DA351A3FB-23M
7 43046442 Valve, Packed, 9.52 DIA
8 43146680 Valve, Packed, 12.7
10 43047527 Tube, Capillary, ID 2.0 × 2000L
27 43146715 Valve, Checked, BCV-804DY
29 43146736 Valve, Checked, YCV3-22GME-1
30 43146676 Joint, Check
32 43146727 Valve, Gas, DIA 25
33 43146711 Valve, 2-Way, VPV-122DQ1
35 43146699 Valve, Ball, B5/8F, Rohs
37 43146712 Valve, 2-Way, VPV-303DQ1
38 43146730 Valve, 2-Way, VPV-603DQ2
39 43146734 Valve, Checked, ZGV-S55B-A
40 43146709 Valve, PMV, HAM-BD24TF-1
43 4314Q060 Strainer, DIA 12.7, C1220T-H
44 4314Q056 Strainer, DIA 25.4, C1220T-H
45 4314Q058 Strainer, DIA 25.4
46 4314Q052 Strainer, DIA 45, C1220T-H
47 4314Q053 Strainer, DIA 21, C1220T-H
48 43148220 Plug, Fusible, 73°C
49 43148202 Tank, Liquid
50 43148192 Separator
52 43148200 Accumulator, 20L
53 43149377 Sensor Assembly, Low Pressure, 150XA4-L1
54 43149378 Sensor Assembly, High Pressure, 150XA4-H3
64 4314G264 Condenser Assembly, Three Row
65 4314G265 Condenser Assembly, Three Row
66 4314G249 Condenser Assembly, One Row
67 4314G250 Condenser Assembly, One Row
68 43151283 Switch, Pressure, ACB-4UB32W
75 44246235 Tube, Capillary, Bypass, 0.8 DIA
76 44246236 Tube, Capillary, Bypass, 1.0 DIA
77 44246239 Tube, Capillary, 1.2 DIA
79 4314Q054 Strainer, DIA 12.7, C1220T-H
80 4314Q055 Strainer, DIA 19.05, C1220T-H
81 4314Q057 Strainer, DIA 25.4, C1220T-H
82 4314Q059 Strainer, DIA 25.4
