Toshiba MMY-MAP0802FT8-E - Outdoor Unit Exploded Views and Parts List: FT8-E Series; FT8-E Series Parts List

39
Location
Part No. Description
No.
4 43041781 Compressor, DA421A3FB-23M
5 43046442 Valve, Packed, 9.52 DIA
6 43146680 Valve, Packed, 12.7
7 43047401 Bonnet, 3/8, IN
9 43063332 Holder, Sensor
14 43100265 Cabinet, Up
15 43119466 Guard, Fan
17 43120219 Fan, Propeller, DIA 710, ASG
18 4312C004 Motor, Fan, DC 280V, MF-230-600-1R
19 43146715 Valve, Checked, BCV-804DY
20 43146736 Valve, Checked, YCV3-22GME-1
21 43146676 Joint, Check
22 43146722 Coil, Solenoid, STF-01AJ502E1
23 43146727 Valve, Gas, DIA 25
24 43146711 Valve, 2-Way, VPV-122DQ1
25 43146698 Valve, 4-Way, STF-0731G
26 43146699 Valve, Ball, B5/8F, Rohs
28 43146730 Valve, 2-Way, VPV-603DQ2
29 43146734 Valve, Check, ZGV-S55B-A
30 43146709 Valve, PMV, HAM-BD24TF-1
31 43146708 Coil, PMV, HAM-MD12TF-3
32 43146731 Valve, 2-Way, VPV-1204DQ50
33 43147195 Bonnet, 1/2, IN
34 4314Q052 Strainer, DIA 45, C1220T-H
35 4314Q053 Strainer, DIA 21, C1220T-H
36 4314Q060 Strainer, DIA 12.7, C1220T-H
38 4314Q055 Strainer, DIA 19.05, C1220T-H
39 4314Q056 Strainer, DIA 25.4, C1220T-H
40 4314Q057 Strainer, DIA 25.4, C1220T-H
41 4314Q058 Strainer, DIA 25.4
42 43148220 Plug, Fusible, 73°C
43 43148202 Tank, Liquid
44 43148192 Separator
45 43146737 Valve, Checked, YCV5P-33GME-1
46 43148200 Accumulator, 20L
47 43149377 Sensor Assembly, Low Pressure, 150XA4-L1
57 4314G272 Condenser Assembly, Three Row
58 4314G273 Condenser Assembly, Three Row
60 43157276 Heater, Case, 29W, AC 240V
61 431S8087 Owner’s Manual, MMY-MAP1202FT8-E
63 43197175 Nut, Flange, M10, SWCH12R
64 43197176 Washer, SPHC
69 43100396 Panel, CGCD2-Z08-C77
70 43100406 Cabinet Assembly, Front, Up
71 43100407 Cabinet Assembly, Back, Up
72 43100408 Cabinet Assembly, Side, Left
73 43100409 Cabinet Assembly, Side, Right
74 43100410 Cabinet Assembly, Front, Down
75 43100411 Cabinet Assembly, Back, Down
76 43194029 Bonnet
721 43031110 Diode, 25A, 600V, *GBPC-2506
722 43155214 Resistor, 1Ω, 20W
723 43158207 Reactor, CH-68
724 4316V362 P.C. Board Assembly, Passive, MCC-1580
Model Name MMY-MAP
1202FT8-E 1002FT8-E 0802FT8-E
222
111
111
111
111
111
111
111
111
222
333
333
111
111
777
111
111
111
222
333
333
111
111
111
111
222
111
222
111
111
111
111
111
111
111
111
111
111
333
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
