Toshiba MMY-MAP0802FT8-E - Outdoor Unit Exploded Views and Parts List: FT8-E Series; FT8-E Series Parts List (Continued)

41
Location
Part No. Description
No.
4 43041781 Compressor, DA421A3FB-23M
10 43049683 Band, DIA 8, EPDM
11 43050407 Thermostat, Bimetal
12 43063317 Holder, Thermostat
21 43146676 Joint, Check
24 43146711 Valve, 2-Way, VPV-122DQ1
25 43146698 Valve, 4-Way, STF-0731G
27 43146712 Valve, 2-Way, VPV-303DQ1
28 43146730 Valve, 2-Way, VPV-603DQ2
30 43146709 Valve, PMV, HAM-BD24TF-1
31 43146708 Coil, PMV, HAM-MD12TF-3
32 43146731 Valve, 2-Way, VPV-1204DQ50
37 4314Q054 Strainer, DIA 12.7, C1220T-H
42 43148220 Plug, Fusible, 73°C
43 43148202 Tank, Liquid
44 43148192 Separator
46 43148200 Accumulator, 20L
47 43149377 Sensor Assembly, Low Pressure, 150XA4-L1
48 43149378 Sensor Assembly, High Pressure, 150XA4-H3
49 43149317 Rubber, Supporter, Pipe, DIA 25.4
50 43149318 Rubber, Supporter, Pipe, DIA 19.0
52 43149320 Rubber, Supporter, Pipe, DIA 8.0
53 43149321 Rubber, Supporter, Pipe, DIA 6.4
54 43149323 Rubber, Supporter, Pipe, DIA 9.52–12.7
55 43149324 Rubber, Cushion, EPDM
56 43149325 Band, Fix, SUS304
59 43151283 Switch, Pressure, ACB-4UB32W
62 43197184 Bolt, Compressor, M6, SWCH 18A
65 43146660 Coil, Solenoid, AV 220 – 240V, 50Hz
Model Name MMY-MAP
1202FT8-E 1002FT8-E 0802FT8-E
222
222
222
222
333
777
111
333
111
333
333
111
333
111
111
111
111
111
111
111
555
333
222
444
666
666
222
666
12 12 12
