Toshiba MMY-MAP0802FT8-E - Outdoor Unit Exploded Views and Parts List: FT8-E Series; FT8-E Series Parts List (Continued)

43
Location
Part No. Description
No.
1 43146721 Valve, Checked, BCV-603DY
4 43041781 Compressor, DA421A3FB-23M
5 43046442 Valve, Packed, 9.52 DIA
6 43146680 Valve, Packed, 12.7
8 43047527 Tube, Capillary, ID 2.0 × 2000L
17 43120219 Fan, Propeller, DIA 710, ASG
19 43146715 Valve, Checked, BCV-804DY
20 43146736 Valve, Checked, YCV3-22GME-1
21 43146676 Joint, Check
23 43146727 Valve, Gas, DIA 25
24 43146711 Valve, 2-Way, VPV-122DQ1
25 43146698 Valve, 4-Way, STF-0731G
26 43146699 Valve, Ball, B5/8F, Rohs
27 43146712 Valve, 2-Way, VPV-303DQ1
28 43146730 Valve, 2-Way, VPV-603DQ2
29 43146734 Valve, Check, ZGV-S55B-A
30 43146709 Valve, PMV, HAM-BD24TF-1
32 43146731 Valve, 2-Way, VPV-1204DQ50
34 4314Q052 Strainer, DIA 45, C1220T-H
35 4314Q053 Strainer, DIA 21, C1220T-H
37 4314Q054 Strainer, DIA 12.7, C1220T-H
38 4314Q055 Strainer, DIA 19.05, C1220T-H
39 4314Q056 Strainer, DIA 25.4, C1220T-H
40 4314Q057 Strainer, DIA 25.4, C1220T-H
41 4314Q058 Strainer, DIA 25.4
42 43148220 Plug, Fusible, 73°C
43 43148202 Tank, Liquid
44 43148192 Separator
45 43146737 Valve, Check, YCV5P-33GME-1
46 43148200 Accumulator, 20L
47 43149377 Sensor Assembly, Low Pressure, 150XA4-L1
48 43149378 Sensor Assembly, High Pressure, 150XA4-H3
57 4314G272 Condenser Assembly, Three Row
58 4314G273 Condenser Assembly, Three Row
59 43151283 Switch, Pressure, ACB-4UB32W
66 44246235 Tube, Capillary, Bypass, 0.8 DIA
67 44246236 Tube, Capillary, Bypass, 1.0 DIA
68 44246239 Tube, Capillary, Bypass, 1.2 DIA
Model Name MMY-MAP
1202FT8-E 1002FT8-E 0802FT8-E
111
222
111
111
111
111
222
333
333
111
777
111
111
333
111
222
333
111
111
111
333
111
222
111
111
111
111
111
111
111
111
111
111
111
222
111
111
111
