Toshiba nv-pack Series - Page 12

6F8C1621
x
Chapter 4
Operati
on
...45
Chapter 5
Troubleshooting
...47
Chapter 6
Maintenance and
I
nspection
...49
6.1 Inspection ························································· 50
6.1.1 Daily inspection ················································· 50
6.1.2 Periodical inspection ·········································· 51
6.2 Life Limited Parts ··············································· 51
Chapter 7
Application
I
nterface
...53
7.1 Information by Socket (Reserved) ························· 55
7.1.1 Configuration of information by socket ······················ 55
7.1.2 Referring to information by socket ························· 56
7.1.3 Timing of generation of information by socket ··········· 57
7.2 Transmission Path Diagnosis Information ·············· 59
7.2.1 Configuration of the scan data healthy map ············· 59
7.2.2 Configuration of the scan data unhealthy map ·········· 60
7.2.3 Configuration of the scan data talker map ················ 61
7.2.4 Configuration of RAS information ·························· 62
7.2.5 Configuration of in-ring map ································· 64
7.3 Usage Constraints ·············································· 65
Appendix A
Specifications
...67
A.1 General Specifications ········································ 68
A.2 TC-net 100 Transmission Specifications ················· 70
A.3 Function Specifications ······································· 71
