9-16 User’s Manual
Qosmio G40
Battery Charger
The battery charger provides a convenient way to charge up to two Lithium
Ion battery packs without requiring the use of your computer.
USB floppy disk drive
The USB floppy disk drive accommodates either a 1.44MB or 720KB a
3 2/1" floppy disk and connects to one of the computer’s USB ports.
USB floppy disk drive
The USB floppy disk drive is available only as an option.
USB connector Insert this connector into one of the free USB
ports of your computer.
Disk-In-Use Indicator This indicator glows when the floppy disk is being
accessed.
Floppy disk slot Insert a floppy disk into this slot.
Eject button When a floppy disk is fully seated in the drive, the
eject button will pop out. In order to remove the
disk, push the eject button in order to cause it to
partially pop out of the drive and then remove it.
Eject button
Floppy disk slot
Disk-In-Use Indicator
USB connector
Check the Disk-In-Use indicator when you use the floppy disk drive. Do
not press the eject button or turn off the computer while the light is glowing.
Doing so could destroy data and damage the floppy disk or the drive.
