2-4 User’s Manual
Qosmio G40
Right side
The following figure shows the computer’s right side.
The right side of the computer
Modem jack
VIDEO-IN port
S-Video-in port
Headphone jack
Headphone (S/PDIF)
jack
Microphone jack
Line-in jack
Universal Serial Bus
(USB 2.0) port
Headphone jack A 3.5 mm mini headphone jack enables
connection of stereo headphones.
Headphone (S/PDIF)
jack
This jack lets you connect digital speakers or a
stereo headphone (16 ohm minimum). When you
connect a digital speaker or headphones, the
internal speaker is automatically disabled.
This jack can be used also as S/PDIF jack and
enables connection of optical digital
correspondence apparatus.
Microphone jack A 3.5 mm mini microphone jack enables
connection of a three-conductor mini jack for
monaural microphone input.
Line-in jack A standard 3.5 mm mini line-in jack enables
connection of a stereo device for audio input.
Universal Serial Bus
(USB 2.0) port
The Universal Serial Bus port, which complies
with the USB 2.0 standard, is provided on the
right side of the computer.
Modem jack The modem jack allows you use to attach a
modular cable in order to connect the internal
modem directly to a telephone line.
