User’s Manual 2-6
The Grand Tour
Back side
Figure 2-4 shows the computer’s back side.
Figure 2-4 The computer’s back side
Underside
Figure 2-5 shows the underside of the computer. Make sure the display is
closed before turning over your computer.
Figure 2-5 The underside of the computer
Battery pack lock Slide the battery pack lock to unlocked position to
free the battery release latch.
Memory module
cover
This cover protects two memory module sockets.
One or two modules are preinstalled.
1.BATTEER PACK LOCK
2.MEMORY MODULE COVER
3.BATTERY PACK
4.BATTERY RELEASE LATCH
