Toshiba SD-V393SU2 - Electrical Replacement Parts List

ELECTRICAL REPLACEMENT PARTS LIST
Location No. TSB P/N Reference No. Description
RESISTORS
! R501 BZ210219 R0G3K2335K RC 3.3M OHM 1/2W
! R502 BZ210039 R3X181010J R,METAL OXIDE 1 OHM 1W
! R503 BZ210206 R002T2155J RC 1.5M OHM 1/2W
! R504 AE000145 R002T2561J RC 560 OHM 1/2W
! R512 AE001779 R3X181683J R,METAL OXIDE 68K OHM 1W
! R516 AE005735 R63881R22J R,FUSE 0.22 OHM 1W
! R517 BZ210180 R002T2102J RC 1K OHM 1/2W
R8033 AE007385 R00202471J RC 470 OHM 1/2W
CAPACITORS
! C501 BZ110119 E02LF2222M CE 2200 UF 16V
! C502 BZ110025 P2122B224M CMP 0.22 UF 275V ECQUL
! C504 BZ110076 E02LF1222M CE 2200 UF 10V
! C505 AD301535 E02LU2101M CE 100 UF 16V
! C511 BZ110186 E62QFC470M CE 47 UF 200V
C513 BZ110175 C03L0R7H2K CC 220 PF 2KV R
! C514 AD301535 E02LU2101M CE 100 UF 16V
! C515 AE001722 C0J0B0514K CC 0.01 UF 500V B
! C516 BZ110256 CC3LE0MH3M CC 0.0022UF 250V
! C518 AE004691 E61FF0222D CE 2200 UF 6.3V
! C519 AD301535 E02LU2101M CE 100 UF 16V
C525 BZ110172 C03L0R7U2K CC 680 PF 2KV R
! C526 BZ110256 CC3LE0MH3M CC 0.0022UF 250V
! C531 AE001723 C0JTB05S2K CC 560 PF 500V B
! C540 BZ110186 E62QFC470M CE 47 UF 200V
DIODES
D501 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
! D502 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC
! D503 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC
D504 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
! D505 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC
! D506 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC
! D507 BZ410007 D23TGP15J0 DIODE,SILICON RGP15J-G23
D508 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D509 BZ410103 D2WXGP10J0 DIODE,RECTIFIER RGP10J-EIC
! D510 BZ410113 D97U02201B DIODE,ZENER MTZJ22B T-77
! D511 BZ410115 D2LKB340L0 DIODE,SCHOTTKY SB340L-6737
D512 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
! D513 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC
D514 AD300070 D97U01201B DIODE,ZENER MTZJ12B T-77
! D515 BZ410033 D28T21DQN4 DIODE,SCHOTTKY 21DQ04N-TA2B1
D516 BZ410020 D97U05R11B DIODE,ZENER MTZJ5.1B T-77
D518 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
! D519 BZ410022 D97U06R81B DIODE,ZENER MTZJ6.8B T-77
! D522 AE006060 D28T0ERB20 DIODE,RECTIFIER 10ERB20-TA1B2
! D523 BZ410037 D97U03301B DIODE,ZENER MTZJ33B T-77
D524 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D526 AD302208 D97U03R31B DIODE,ZENER MTZJ3.3B T-77
! D527 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC
D528 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
! D529 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC
D602 AE001703 0021E5Q212 LED LTL-1CHGT-002A
D656 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC
D685 AE001703 0021E5Q212 LED LTL-1CHGT-002A
D2303 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D2304 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D3001 AD301638 0010E00330 INFRARED LED LTE-3271T-012A-O
D3002 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3007 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D3009 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D4002 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D4003 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D4004 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D4005 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D8004 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D8005 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D8006 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77
D8111 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
D8112 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17
ICS
IC101 AE005890 I03F3206ME IC LA71206M-MPB-E
! IC501 AD302211 I1KJ9A431A IC KIA431A-AT
! IC502 BZ611089 I1KA98R09A IC KIA78R09API
! IC503 AE002809 000220002W PHOTO COUPLER PS2561AL1-1-V(W)
IC701 AE004692 I03F670BM0 IC LA72670BM-L-MPB-E
! IC2301 AE003581 I03F065650 IC LA6565-TE-L-E
K4-1
